    Automatic Ride On Electric Pallet Stacker AC Motor 1500kg Yellow Color

    Ask Lasest Price
    Brand Name : M&D
    Model Number : CDD15 - 920
    Certification : CE,ISO
    Price : negotiable
    Supply Ability : 500units/month
    Delivery Time : 3-20days
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    • Product Details
    • Company Profile

    Automatic Ride On Electric Pallet Stacker AC Motor 1500kg Yellow Color

    Detailed Product Description
    Capacity:1500kgMax. Lifting Height:2500-5600mm
    Color:Yellow Or CustomizedAisle Width For Pallets 800*1200 Lengthways:2515mm
    Turning Radius:1655mmBattery:24V240AH
    Travel Speed, Laden/unladen:6.5/6.7km/hService Weight:1240-1580kg

    AC motor 1500kg rider electric pallet stacker using Germany Krupp mast


    Quick Details:

    Description: Electric Rider Stacker CDDK15
    Capacity: 1500kg
    Max. lifting height: 2500/3000/3300/3500/4500/5000/5600mm
    Fork dimensions: 60/180/1070(1150)mm

    Aisle width for pallets: 2515mm
    Lifting speed, laden/unladen: 0.11/0.14m/s

    Lowering speed, laden/unladen: 0.12/0.12m/s

    Battery: 24V240AH



    Advantages:

    • AC motor eliminates carbon brush replacement.
    • Multi function display instrument has electric power display, fault code display, working time cumulative display and fast/slow speed display.
    • The side door and the battery cover can be opened, the battery can pull out from the side, which is beneficial to the exchange and maintenance of the battery.
    • There is a shock absorber to reduce noise.
    • The handle is equipped with emergency reverse switch, make the electric pallet stacker operation more safe.
    • The eletric pallet stacker is braked when the handle in both vertical and horizontal directions, so as to improve the safety of the whole vehicle.
    • Emergency power off switch.
    • Automatic deceleration function.
    • Built in unloading valve to protect the eletric pallet stacker from overloading and improve reliability.
    • Stepless speed change control.
    • Low center of gravity.
    • Vertical driving wheel.
    • Frame and mast is separable.
    • Free lift.
    • Strong imported mast.
    • CANbus technology.
    SPECIFICATIONS OF RIDER ELECTRIC PALLET STACKER
    ModelCDDK15
    Load capacitykg1500
    Load center distancemm600
    Load distance, centre of drive axle to forkmm672
    Fork height, loweredmm85
    Tyre size, frontmm250*70
    Tyre size, rearmm80*84
    Additional wheels (dimensions)mm150*60
    Height, mast loweredmm1735/1985/2135/2235/2050/2210/2410
    Free lift (option 2500-3500mm)mm1300/1550/1700/1800/1570/1740/1940
    Max. lifting heightmm2500/3000/3300/3500/4500/5000/5600
    Height, mast extendedmm2955/3455/3755/3955/5030/5510/6110
    Initial liftmm1150/1450
    Overall lengthmm2020/2100
    Length to face of forksmm950
    Overall widthmm850
    Fork dimensionsmm60/180/1070(1150)
    Width overall forksmm570/695
    Aisle width for pallets 800*1200 lengthwaysmm2515
    Turning radiusmm1655
    Travel speed, laden/unladenkm/h6.5/6.7
    Lift speed, laden/unladenm/s0.11/0.14
    Lowering speed, laden/unladenm/s0.12/0.12
    BatteryV/Ah24/240
    Service weightkg1180/1205/1220/1230/1280/1300/1320

    Automatic Ride On Electric Pallet Stacker AC Motor 1500kg Yellow Color


    Automatic Ride On Electric Pallet Stacker AC Motor 1500kg Yellow Color



    Advantage:


    1,EPS Electric Power Steering System,Operation force light,Save energy,Low noise.

    2.Durable and rigid frame construction ensure the stackers to handle heavy loads.

    3.Hourmeter and BDI(Battery Discharge Indicator)on time informs the operator of recharge requirements.

    4.Power sylinder prevents wheels slip.

    5.Tilter head ergonomically designed for maximum opertor comfortable,and control buttons positioned to allow operation with either hand.

    6.limit switch mounted on top of mast to precisely set the max.Lifting height,avoid any risk of lifting motor overload.

    7.Robust and rigid mast configuration optimize stackers lifting stability and safety.

    8.Vertical drive system,Driving floating adjustable system design.

    9.Wide ligs

    10. handling equipments
