4 WD green small diesel garden tractors,agriculture mini tractor
Strong Power
Weichai high pressure common rail engine is equipped for strong
power and large torque reserve, thus meeting requirements of
different customers. Yuchai engine and Dongfanghong engine are for
optional.
Optimized power emission and performance with low fuel consumption
and high reliability
Advanced Technology
16F+8R shuttle-type transmission is used with reasonable match of
speed. Working sites adaptability is good and operation is easy and
comfortable.
Central transmission is adopting spiral bevel gear. Final
transmission is adopting planetary gear reduction hub.
Imported German LUK clutch is used for flexible operation and high
reliability.
Cardan joint 4WD front drive shaft is used for large torque and
high reliability.
High Durability
Separate oil supply hydraulic system with high clean capacity, low
failure rate and high reliability
Dry type air filter is equipped with block alarm.
Excellent Adaptability
Dual oil cylinder pressure lifter with height limitator. Tilling
depth adjustment is using position adjustment and floating control.
PTO of 760/850 r/min, 540/1000 r/min, 760/1000r/min and
540/760r/min can be choose between. Various agricultural working
devices can be equipped.
Comfortable Drive Experience
Full hydraulic steering system is adopted, which makes drive more
easily, and steering more flexible. Steering wheel can be adjusted.
Rearview system is optional for enlarged view, and make it easier
for working attachment control and hitch.
Fully enclosed comfortable cab is used with ample space and
comfortable operation.
Technical Parameters
| Drive Type | 4WD |
Engine Rated Power(kW) | 118 |
| Engine Rated Speed(r/min) | 2200 |
Engine Oil Supply System | High Pressure Common Rail |
Overall Dimension( L*W*H) (mm) | 5050×2200×3150(cab roof)/2995(safety shelf ) |
Min. Operating Weight(kg) | 5400/5080 (safety shelf) |
Tire Specification | 14.9-26/18.4-38 Optional: 14.9-26 middle pattern tire 1834-38
middle pattern tire |
| Transmission tyoe | Mechanical stepped shift speed |
| Transmission (forward/reverse) | 16F+8R |
| Front Wheel Track(mm) | 1672 |
| Rear Wheel Track(mm) | 1680 |
| Wheel Base(mm) | 2650 |
| PTO Shaft Speed(r/min) | 760/850 optional: 540/1000, 540/760,760/1000 |
chinese small farm tractor,18 4-34 tires farm tractor
1. Adopt Xinchai diesel engine, good reliability, large reserve of
torque, low fuel consumption, high economic efficiency;
2. Double-function cluth, 10 inches, high transimission capacity,
reliable, comfortable manipulation;
3. Gearbox using 4×3(1+1) engaging sleeve, shuttle-type gearshift,
there are 12 forwards gears, 12 reserves gears, reasonable match
between the gears, and have high efficiency;
4. Independent power take off device, smooth transmission, large
capacity, speed(540/760, 540/1000 r/mim) for selection to meet the
different operation requirements;
5. Full hydraulic front wheels steering, independent oil circuit
for steering system, manipulating flexible, realiable and save
energy;
6. Adopt hrdrostatic disc-type brakes, a large braking torque, the
braking effect is good;
7. Adopt high pressure tyoe lifting device, realiable, easy
maintenance, multi-hydraulic output can be optioned;
8. Final transmission adopts planetary gear mechanism, compact
structure, large reduction ratio;
9. New streamlined appearance, generous, modern, fashion;
10. Control levers can be mounted at side as optional, more
convenient and comfortable.
