    Super Narrow 2 Ton Hand Pallet Truck 160mm Steering Wheel Customized Design

    Ask Lasest Price
    Brand Name : MD
    Model Number : DF-20
    Certification : CE ISO
    Price : negotiable
    Supply Ability : 1000 set per month
    • Product Details
    • Company Profile

    Super Narrow 2 Ton Hand Pallet Truck 160mm Steering Wheel Customized Design

    Super Narrow 2 Ton Hand Pallet Truck 160mm Steering Wheel Customized Design
    Detailed Product Description
    Capacity:2000kgLowered Fork Height:75mm
    Lifting Height:190mmHeight Of Handleless:401.5mm
    Width Overall Forks:320/390/406mmSteering Wheel:160mm
    Fork Wheel:70mmService Weight:65kg

    Super narrow 2000kg hand pallet truck for ultra narrow pallet


    Quick Details


    Model: Super narrow hand pallet truck BFZ

    ​​​Capacity: 2000kg

    Lowered fork height: 75mm

    Total lift height: 190mm

    Height of handleless: 401.5mm

    ​Width overall forks: 320/390/406mm

    ​Steering wheel: 160mm

    Fork wheel: 70mm

    ​Service weight: 65kg


    Advantages:

    • Product name Super Narrow Hand Pallet Truck.

    • The pallet truck is very narrow, width over forks 320/390/406mm.

    • 2000kg Max Capacity.

    • ​Suitable for super narrow pallets.

    SPECIFICATIONS
    ModelBFZ
    Capacitykg2000
    Lowered fork heightmm75
    Total lift heightmm190
    Height of handlelessmm401.5
    Fork lengthmm800
    Width overall forksmm320/390/406
    Steering wheelmm160
    Fork wheelmm70
    Truck weightkg65


    Super Narrow 2 Ton Hand Pallet Truck 160mm Steering Wheel Customized Design


    Super Narrow 2 Ton Hand Pallet Truck 160mm Steering Wheel Customized Design


    Hand pallet truck also known as manual pallet truck, hand pallet truck when use the carrying goods fork into the tray hole, by the ability to drive hydraulic system to realize the pallet load lifting and falling, and pulled by human complete handling operations.

    It is the simplest and most effective tray in the transport, the most common type of loading and unloading,handling tools,widely used in logistics,warehouses, factories, hospitals, schools, shopping malls, airports, stadiums, station, airport and so on


    Brand New stainless steel hand pallet truck of superior quality and competitive price

    We used 304 stainless steel totally except wheels.

    World class quality

    Rubber coated handle comfortable even under extreme temperature conditions.
    Fully sealed galvanized hydraulic unit housing.

    Single valve cartridge for easy maintenance.
    Powder coated chassis made of high grade steel.
    Lead-in and lead-out rollers reduce damage to pallets.


    -Easy handling & easy lifting.

    -Baked enamel Coating.

    -With an overload relief value to avoid misuse due to over Loading.

    -Steer and fork wheels are made by steel and covered by Polyurethane.


    ModelMS20SMS20LMS25SMS25LMS30SMS30L
    Capacity(kg)200020002500250030003000
    Lifting Height(mm)115
    Min. Fork Height(mm)85(or 75)
    Max. Fork Height(mm)200(190)
    Fork Lenght(mm)115012201150122011501220
    Overall Width(mm)540685540685540685
    Fork width(mm)160
    Load Roller(mm)Tandem 82x70, Single 82x93, Nylon, Polyurethane
    Steering Wheel(mm)200x50(Nylon, polyurethane or Rubber)
    Net Weight(kg)808382858587

    Special fork length available, 800mm, 950mm, 1000mm, 1500mm, 2000mm


    Overall weight:220kg,

    packing list: 2300*550*750/2300*700*730mm ,

    by sea & trucks , 112UNITS FOR 20’C ,188 UNITS FOR 40’C ,

    HS CODE: 8716 8000 00


    FAQ

    Q1:Are you Factory?Yes
    Q2:Are the forklift trucks covered by a warranty?Yes.All our machines carry a full 1 year major parts warranty.
    Q3:Can I get discounts?Yes.For big order,old customer and frequent customers,we give resonable discounts.
    Q4:Can I place mix order?For example,I need 2 pc Electric stacker and 1 pc Hand Pallet Truck,can this ok?Yes,of course.You can mix diff model as your wish.
    Q5:Can you add our own logo on the products or use our designs?

    Yes,of course you can add logo on your products!

    We provide OEM/ODM service.I addition,we promise your design would protect by law,we won't tell anyone else about this. It's your own copyright.

    Q6:Can you send the machine to my factory in other city to load the container?Yes,please tell US the detail address,we can arrange to send your factory in time.
    Q7:How can the machines be send to us?The transportation depends on client's choice,usually by sea,by train,by air etc.You also can choose other shipping method and inform us before shipment
