    EPA 4 Yanmar Engine Backhoe Wheel Loader Steel Red Color Mini Wheel Skid Steer

    Ask Lasest Price
    Brand Name : M&D
    Model Number : ZL50
    Certification : CE ISO
    Price : negotiable
    Supply Ability : 200 set per month
    Delivery Time : 15-20 days
    • Product Details
    • Company Profile

    EPA 4 Yanmar Engine Backhoe Wheel Loader Steel Red Color Mini Wheel Skid Steer

    EPA 4 Yanmar Engine Backhoe Wheel Loader Steel Red Color Mini Wheel Skid Steer


    Overview:


    Rated load: 1200kg-1600kg

    * Engine: Standard Yunnei YN 27 ( 42kw), Optional: Xinchai 398(36.8KW) engine( EuroIII) &Commins 37kw ( EPA)

    * Frame: Broaden and heighten front frame to protect drive shaft from broken by hard object and enhanced the machine stability

    * Cab: E-coating cabin with high antirust capacity, and cab with skylight, rear view camera to expand the drivers view

    * Engine Hood: 5mm iron steel engine hood with e-coating, with excellent antirust capacity can meet family car level

    * Hydraulic System: Fully Hystat Operation, easy to operated the machine

    * Tire: 20.5/70-16 Standard tires, 16 layer high pressure load more weight and prolong tire life

    * Drive system: Continuously variable transmission, easy to drive


    The loader machine adopts the complete machine is rationally distributed and compact; it is comfortable and convenient to handle,the turning radius is small and the cost performance is high. It is widely used in municipal administration, the construction of projects such as the building, the oil field, water conservancy,the forest farm, the military project, and so on.

    It also can be used in carrying and leveling and can carry on the flexible and swift homework to scarp heap and waste residue of the large and medium-sized enterprise.

    Match with high quality engine, low, low blow off of noise, driving force forceful, twist from when reserve is big. The driving force loader special use fixing an axis changes the gear speed change box, structure is compact, drive is efficient, structure stiffness is big, life-span is long.

    The dyadic center equidistance hinge joint fleet of carriage, makes turn the radius is small, the expedient function is good.The drive’s cab, wide vision, air-conditioning, operation environment sealing off subtraction vibrating, allocating are comfortable, safe. Various machines and tools such as may select and use for –in-one bucket, breaking a hammer to pieces, the function are especially all in readiness.


    JC100 skid steer loader 1200kgs

    Specifications:


    Wheel Loader

    Overall Dimension5620*1900*2800mmRated Load1400kg
    Operate Weight3610kgArm Thickness25mm
    Bucket Width1850mmBucket Capacity0.8m³
    Max. Dumping Height2850mmBattery80A
    EngineYunnei 495Rated Power60kw(81.6hp)
    Four-CylinderTypeTurbocharge
    Yunnei 4100 TurbochargeRated Power65kw(88.4hp)

    Transmission

    System

    Gearbox Model265 AutomaticAxle18E Small Hub Reduction
    Drive Model4WDBrake ModelGas Cap Oil Brake
    Tyre SizeSize23.5/70-16ModelRoad Tyre
    Package1 set in 1*20GP container, 3 sets in 1*40 HQ ContainerMOQ1 Set
    FrameEnhancedColour

    Yellow, Red,Camouflage....

    EPA 4 Yanmar 4TNV98C 49.5kw engine
    Mitsubishi Europe III engine
    Solid tyre 31x10-16F2A
    Closed cablin
    Air conditioner
    Heater
    Steel track outboard on tyres:(10-16.5)

    Advantages:

    1. Self produced front and rear frames, heat treatment with high rigidity
    2. Powerful engine with global warranty and parts service
    3. Competitive price with high performance
    4. Real warranty supplied by original manufacturer

    5. More than 10 years experiences

    6.China Construction Machine 5ton Front Wheel Loader for Sale


    Engine:XINCHAI engine

    .U.S. Donaldson III air filter

    .U.S. Sauor double pump,France POCLAIN radial plunger motor with parking brake and flush valve

    .US Timken bearing, impported 100H chain, the tension of chain can be easily adjusted

    .Italy Walvoil triple multi-way valve,US Permco gear pump

    .tubeless tyre 10-16.5, 12 ply rating reinforced tyre

    .Manipulate mode:mechanical control walking system by hands and working system by feet

    .Semi-closed cabin with glass ceiling, caution light and back-up buzzer, left and right rearview mirror, front and back steering lamp,without front door and side glass

    .Rated load capacity:700kg

    .output height:2300mm

    .Swing-out All- aliumum radiator

    .Arm safety lock

    . Radial lift


    joystick
