3 Stage Lifting Height 2500mm Electric Pallet Stacker

    Buy cheap 3 Stage Lifting Height 2500mm Electric Pallet Stacker from wholesalers

    Buy cheap 3 Stage Lifting Height 2500mm Electric Pallet Stacker from wholesalers
    • Buy cheap 3 Stage Lifting Height 2500mm Electric Pallet Stacker from wholesalers

    3 Stage Lifting Height 2500mm Electric Pallet Stacker

    Ask Lasest Price
    Brand Name : M&D
    Certification : CE,ISO
    Price : negotiable
    Delivery Time : 3-20days
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 500units/month
    • Product Details
    • Company Profile

    3 Stage Lifting Height 2500mm Electric Pallet Stacker

    Lifting Height 3000mm 2500mm 1600mm Full Economic Electric Pallet Stacker


    Product Description
    Parameters
    Unit
    CDD10C-16
    CDD10C-25
    CDD10C-30
    CDD15C-16
    CDD15C-30
    Rated load capacity
    kg
    1000
    1000
    1000
    1500
    1500
    Load center
    mm
    500
    500
    500
    500
    500
    Max. lifting height
    mm
    1600
    2500
    3000
    1600
    3000
    Wheel

    PU solid tire
    Fork size
    mm
    1150×160
    Fork over width
    mm
    560/680
    Overall Length
    mm
    1785
    Overall Width
    mm
    800
    Overall height when mast lowered
    mm
    2075
    1825
    2075
    2075
    1825
    Max. height when fork is lifiting
    mm
    2075
    3037
    3537
    2075
    3537
    Fork ground clearance
    mm
    85
    Turning radius
    Wa(mm)
    1380
    Distance from front wheels to the fork ends
    mm
    430
    Min stacking aisle 1000*1000 pallet
    mm
    2155
    Max travel speed No load/Full load
    km/h
    4/3.5
    Max grade ability No load/Full load
    %
    6/3
    Total weight
    kg
    506
    546
    566
    596
    666
    Driving wheel
    mm
    210*70
    Front wheel
    mm
    125*50
    Balance wheel
    mm
    125*50
    Battery capacity
    V/Ah
    24V80Ah
    Driving motor
    kw
    75
    Lifting motor
    kw
    2.2
    Walking Adjustable Type

    Holzer type accelerator

    Advantages:​​​​

    • AC motor eliminates carbon brush replacement.
    • Multi function display instrument has electric power display, fault code display, working time cumulative display and fast/slow speed display.
    • The side door and the battery cover can be opened, the battery can pull out from the side, which is beneficial to the exchange and maintenance of the battery.
    • There is a shock absorber to reduce noise.
    • The handle is equipped with emergency reverse switch, make the electric pallet stacker operation more safe.
    • The eletric pallet stacker is braked when the handle in both vertical and horizontal directions, so as to improve the safety of the whole vehicle.
    • Emergency power off switch.
    • Automatic deceleration function.
    • Built in unloading valve to protect the eletric pallet stacker from overloading and improve reliability.
    • Stepless speed change control.
    • Low center of gravity.
    • Vertical driving wheel.
    • Frame and mast is separable.
    • Free lift.
    • Strong imported mast.
    • CANbus technology.

    FAQ


    Q1. What is your terms of packing?
    A: Generally, we pack our goods in paper package and Iron pallet.
    We can pack the goods in your branded boxes after getting your authorization letters.
    Q2. What is your terms of payment?
    A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance. Or As negotiated
    Q3. What is your terms of delivery?
    A: EXW, FOB, CFR, CIF, DDU.
    Q4. How about your delivery time?
    A: Generally, it will take 5 to 30 days after receiving your deposit. The specific delivery time depends on the items and the quantity of your order.
    Q5. Do you test all your goods before delivery?
    A: Yes, we have 100% test before delivery
    Q6: How do you make our business long-term and good relationship?
    A:1. We keep good quality and competitive price to ensure our customers benefit ;
    2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where
    they come from.
